DIN 1478 PIPE BODY JAW & JAW TURNBUCKLE
DIN 1478 jaw & jaw turnbuckle is a type of rigging turnbuckle with jaws at both ends and a closed pipe body.
These jaws can be used to attach the turnbuckle to other components, such as anchor points, hooks, or shackles, allowing for easy connection and adjustment of tension in the system.
Common Uses of Din 1478 Turnbuckle
The din 1478 Turnbuckle is commonly used in applications such as rigging, shipbuilding, construction, and other scenarios where adjustable tensioning is required.
It provides a reliable and straightforward means to tighten or loosen cables or rods, making it useful in a variety of settings.
DIMENSIONS:
| Size | L1(mm) | L2(mm) | L3(mm) | φ1(mm) | φ2(mm) | φ3(mm) | A(mm) | M(mm) | S.W.L | U.W. |
| kgs | kgs | |||||||||
| M6 | 110 | 88 | 58 | 15 | 11.2 | 6 | 8 | 6 | 230 | 0.15 |
| M8 | 110 | 105 | 65 | 17 | 14 | 8 | 10 | 8 | 440 | 0.26 |
| M10 | 125 | 125 | 75 | 21 | 16 | 8 | 12 | 8 | 440 | 0.45 |
| M12 | 125 | 145 | 85 | 25 | 18 | 10 | 16 | 10 | 600 | 0.66 |
| M16 | 170 | 170 | 100 | 30 | 22.8 | 10 | 20 | 12 | 800 | 1.51 |
| M20 | 200 | 184 | 115 | 34 | 27 | 12 | 24 | 16 | 1650 | 2.93 |
| M24 | 255 | 214 | 130 | 42 | 32 | 12 | 30 | 20 | 2600 | 5 |
| M30 | 255 | 251 | 140 | 51 | 38 | 16 | 36 | 24 | 3400 | 9.97 |
| M36 | 295 | 300 | 170 | 63.5 | 50 | 16 | 45 | 28 | 4800 | 14.8 |
