Load-binding chain

Load-binding chain

$0.00

Ratchet chain sling
Robust industrial construction in cast steel with forged components
Equipped with hooks
Safety device prevents thread withdrawal
Meets performance requirements according to BS EN 12195-3

SKU: CHA01 Category:

Ratchet chain load binders are designed to tighten lashing chains for secure load securing and are typically used by truck drivers in the low loader and heavy haulage world.

Our high-quality cast steel chain straps are made of cast steel and feature forged hooks that work with chains ranging from 8 to 13 mm (depending on the model you choose).

Their red coating provides extra protection against the elements and gives them a stylish look. The 355 mm arm provides greater control and allows the user to apply less pressure for a tighter tie in less time.

Safety is always a critical concern with all lifting and fastening equipment, and this innovative series features a safety device to prevent extended/retracted threads from being accidentally pulled out.

It is best used with Grade 80 or Grade 100 chain slings for the best chain slinging solutions.



Chain Dia Lashing Capacity Minimum Breaking Load Weight
mm kgs kgs kgs
8-10 2450 8575 4.82
10-13 4200 14700 5.92
13-16 5900 20650 7.85



Chain Dia L.C. M.B.F. Weight
mm kN kN kgs
8 40 80.4 4.5
10 63 126 5.4
13 100 212 7.7
16 160 322 10.2
