US Type Electric Galvanized Hook & Hook Turnbuckle measurement guide showing open and closed lengths, hook openings, thread diameter and adjustable body dimensions.
US Type Electric Galvanized Hook & Hook Turnbuckle with two open hook ends, adjustable threaded steel body and Heavy Tools branding.

US Turnbuckle Electro G.L with two open hook ends

US Turnbuckle Electro G.L with two open hook ends – Heavy-duty galvanized steel tensioning component featuring open hook connections at both ends, designed for controlled tension adjustment in wire rope assemblies, cable systems, structural bracing, fencing, and industrial applications.

Key Features:

  • Construction: Electric Galvanized
  • Configuration: Hook & Hook with adjustable threaded body.
  • Finish: Galvanized for corrosion protection.
  • Working Load Limit (WLL): 500 lb to 21,400 lb.
  • Available Sizes: 1/4″ × 4″ to 1-1/2″ × 24″.
  • Application: Straight or in-line tensioning only.
Add to Quote
Size Data Sheet

Description

US open hook ends US Type Electro Galvanized Turnbuckle

Turnbuckle is a heavy-duty adjustable
tensioning component designed for controlled
adjustment of tension and length in steel wire
rope, cable, structural bracing and general
industrial tensioning systems.

It features open hook connections at both
ends, allowing convenient attachment to
compatible rings.

Key Features

  • Type: US Type Turnbuckle
  • Configuration: Hook & Hook
  • End Connections: Open Hook at Both Ends
  • Construction: Electric Galvanized
  • Finish: Galvanized Steel
  • Function: Adjustable Cable and Wire Rope Tensioning
  • Loading: Straight or In-Line Pull Only
  • Available WLL: 500 lb to 21,400 lb
  • Size Range: 1/4″ × 4″ to 1-1/2″ × 24″
  • Adjustment: Opposing Threaded End Fittings

Product Construction

The Hook & Hook configuration
provides an open hook fitting at each end of the
turnbuckle.

Dimension Reference & Technical Specifications:

US Type Electric Galvanized Hook & Hook Turnbuckle with two open hook ends, adjustable threaded steel body and Heavy Tools branding.
US Type Electric Galvanized Hook & Hook Turnbuckle featuring dual open hook fittings, adjustable threaded body and zinc-electroplated finish for industrial cable tensioning applications.













Size
(inch)		 Working Load
Limit (lb)		 Dimensions (in.) Weight
(lb/pc)
A D E
Closed		 F J
Open		 K
Closed		 M
Open		 N
Closed		 BB
1/4″ × 4″ 500 0.25 0.45 1.59 1.27 11.12 7.12 11.94 7.94 4.00 0.30
5/16″ × 4-1/2″ 800 0.31 0.50 1.94 1.50 12.81 8.31 13.81 9.31 4.50 0.47
3/8″ × 6″ 1,200 0.38 0.56 2.30 1.77 16.50 10.50 17.72 11.72 6.00 0.78
1/2″ × 6″ 2,200 0.44 0.66 2.94 2.28 18.82 11.82 20.38 13.38 6.00 1.60
1/2″ × 9″ 2,200 0.50 0.66 2.94 2.28 24.82 14.82 26.38 16.38 9.00 1.83
1/2″ × 12″ 2,200 0.50 0.66 2.94 2.28 30.82 17.82 32.38 19.38 12.00 2.28
5/8″ × 6″ 3,500 0.50 0.90 3.69 2.81 20.50 13.25 22.50 15.25 6.00 2.75
5/8″ × 9″ 3,500 0.63 0.90 3.69 2.81 26.50 16.25 28.50 18.25 9.00 3.38
5/8″ × 12″ 3,500 0.63 0.90 3.69 2.81 32.50 19.25 34.50 21.25 12.00 3.50
3/4″ × 6″ 5,200 0.75 0.98 4.52 3.33 22.38 14.88 24.78 17.28 6.00 5.39
3/4″ × 9″ 5,200 0.75 0.98 4.52 3.33 28.38 17.88 30.78 20.28 9.00 5.28
3/4″ × 12″ 5,200 0.75 0.98 4.52 3.33 34.38 20.88 36.78 23.28 12.00 5.43
3/4″ × 18″ 5,200 0.75 0.98 4.52 3.33 46.38 26.88 48.78 29.28 18.00 8.12
7/8″ × 12″ 7,200 0.88 1.13 5.19 3.78 36.00 22.25 38.75 31.00 12.00 8.10
7/8″ × 18″ 7,200 0.88 1.13 5.19 3.78 48.00 28.25 50.75 25.00 18.00 9.95
1″ × 6″ 10,000 1.00 1.25 5.84 4.25 25.63 17.63 28.69 20.69 6.00 9.33
1″ × 12″ 10,000 1.00 1.25 5.84 4.25 37.63 23.63 40.69 26.69 12.00 11.93
1″ × 18″ 10,000 1.00 1.25 5.84 4.25 49.63 29.63 52.69 32.69 18.00 14.00
1″ × 24″ 10,000 1.00 1.25 5.84 4.25 61.63 35.63 64.69 38.69 6.00 17.25
1-1/4″ × 12″ 15,200 1.25 1.50 7.22 5.13 40.44 25.94 44.06 29.56 12.00 20.58
1-1/4″ × 18″ 15,200 1.25 1.50 7.22 5.13 52.44 31.94 55.06 35.56 18.00 23.00
1-1/4″ × 24″ 15,200 1.25 1.50 7.22 5.13 64.44 37.94 68.06 41.56 24.00 27.00
1-1/2″ × 12″ 21,400 1.50 1.88 8.34 5.75 43.94 28.94 47.44 32.44 12.00 27.50
1-1/2″ × 18″ 21,400 1.50 1.88 8.34 5.75 55.96 34.94 59.44 38.44 18.00 31.00
1-1/2″ × 24″ 21,400 1.50 1.88 8.34 5.75 67.94 40.94 71.44 44.44 24.00 37.50
  • Proof Load: 2.5 × Working Load Limit.
  • Safety Factor: 5:1.
  • Fatigue Testing: 1.5 × Working Load Limit.
  • Minimum Breaking Load: 5 × WLL.

Specifications:

Product Type US Type
Configuration Hook & Hook
Material Electric Galvanized
Finish Galvanized
End Connections Open Hook / Open Hook
Loading Direction Straight or In-Line Pull Only
WLL Range 500 lb to 21,400 lb
Size Range 1/4″ × 4″ to 1-1/2″ × 24″
Adjustment Opposing Threaded Rods
Specification Units Imperial – Inches and Pounds

Typical Applications

US Type Electric Galvanized Hook & Hook Turnbuckles
are commonly used:

  • Steel wire rope and cable tensioning
  • Industrial fencing and barrier systems
  • Guy wire tensioning systems
  • Structural bracing assemblies
  • Construction tensioning applications
  • Industrial maintenance installations
  • General-purpose cable adjustment

Request a Quotation

For pricing and availability, please provide:
thread diameter × take-up, required WLL,
quantity and application.

If dimensional compatibility is important,
include the required hook opening or
installation dimensions.


Request a Quote on WhatsApp →

Heavy Tools Company Commercial (L.L.C.)
Industrial & Lifting Equipment – Saudi Arabia
