DIN 1480 Galvanized Hook & Hook Turnbuckle
The DIN 1480 Galvanized Hook & Hook
Turnbuckle is a durable, adjustable tensioning
component designed for steel wire rope, cable systems,
fencing, structural bracing, and industrial applications.
Manufactured from carbon steel with a galvanized
finish, this turnbuckle provides corrosion
protection and reliable tension adjustment.
Its dual hook end fittings allow convenient
attachment and removal from compatible connection points.
The central threaded body features opposing right-hand
and left-hand threads, allowing users to adjust tension
and assembly length by rotating the turnbuckle body.
Key Features
- DIN 1480 Design:
Manufactured in the DIN 1480 dimensional style. - Carbon Steel Construction:
Durable steel body for general industrial tensioning. - Galvanized Finish:
Zinc coating helps resist corrosion in outdoor environments. - Hook & Hook Connections:
Two open hooks for convenient installation and removal. - Adjustable Threaded Body:
Allows controlled tension and length adjustment. - Metric Thread Sizes:
Available sizes subject to supplier confirmation.
Dimensions & Weight Reference
The following dimensional values are reproduced from
the supplied manufacturer’s reference sheet.
All dimensions are in millimeters (mm).
Weights are approximate and expressed in kilograms
per 100 pieces.
The supplied drawing is for the Hook & Eye
configuration. These values are provided as a reference
only and must be verified by the supplier before being
applied to the Hook & Hook product.
| Thread (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
B1 (mm) |
L4 (mm) |
D1 (mm) |
L5 (mm) |
Weight (kg/100 pcs) |
|---|---|---|---|---|---|---|---|---|
| M6 | 110 | 80 | 85 | 8.5 | 80 | 9 | 172 | 9.5 |
| M8 | 110 | 75 | 85 | 11 | 84 | 10 | 182 | 16.5 |
| M10 | 125 | 85 | 112 | 13.5 | 105 | 14 | 213 | 29 |
| M12 | 125 | 80 | 117 | 15.5 | 115 | 16 | 238 | 43 |
| M14 | 140 | 90 | 122 | 18.5 | 122 | 18 | 263 | 62 |
| M16 | 170 | 110 | 138 | 19 | 165 | 22 | 320 | 92 |
| M20 | 200 | 130 | 170 | 20.5 | 167 | 24 | 367 | 163 |
| M22 | 220 | 145 | 185 | 26 | 167 | 27 | 398 | 220 |
| M24 | 255 | 170 | 205 | 26 | 205 | 27 | 447 | 300 |
| M30 | 255 | 160 | 225 | 33 | 255 | 31 | 512 | 460 |
| M36 | 295 | 180 | 255 | 44 | 276 | 43 | 568 | 768 |
| M42 | 330 | 200 | 340 | 48 | 260 | 49 | 683 | 1290 |
| M48 | 355 | 195 | 360 | 58 | 300 | 58 | 755 | 2100 |
Note: The D1 dimension relates to
the eye fitting shown in the reference drawing.
It is not a Hook & Hook measurement.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Hook & Hook Turnbuckle |
| Standard / Design | DIN 1480 |
| Material | Carbon Steel |
| Surface Finish | Galvanized Zinc Coating |
| End Connections | Hook & Hook |
| Thread System | Right-Hand & Left-Hand |
| Size Range | M6–M48 (subject to confirmation) |
| Working Load Limit | Refer to Manufacturer’s Rated Data |
| Applications | Wire Rope, Cable, Fencing & Bracing |
Typical Applications
- Steel wire rope and cable tensioning.
- Industrial fencing and perimeter systems.
- Structural bracing and support cables.
- Construction and general industrial tensioning.
- Outdoor cable assemblies and support systems.
Safety & Installation Guidelines
- Use only for straight or in-line tension.
- Avoid side loading and shock loading.
- Ensure adequate thread engagement.
- Inspect hooks, threads, and body before use.
- Prevent accidental disengagement of open hooks.
- Never exceed the manufacturer’s rated capacity.
Open-hook turnbuckles are not automatically approved
for overhead lifting. Do not use for lifting or
suspending loads unless the manufacturer explicitly
certifies the complete assembly for that purpose.
DIN 1480 dimensional conformity alone does not
establish a WLL, proof load, or safety factor.
